Skidsteer Loader
ST 27
The ST 27 is a heavy-duty R-4 skid steer tyre for machines that are used for construction and heavy-duty applications, mostly operated by specialist contractors. It is built with abrasion resistant compound and has a thick sidewall with rim guard. This protects the rim and reduces downtime.
R-4
A5
Bias
Suitable for
Skidsteer Loader
Compact Wheel Loader
Boom Lift
Technical Data
| TYRE SIZE | REC. RIM (inch) | ALT. RIM (inch) | UNLOADED DIMENSIONS (mm) | TYPE | PLY RATING | LI & SS | ||||
|---|---|---|---|---|---|---|---|---|---|---|
| SW | OD | SLR | RC | |||||||
| 10-16.5 | 8.25 | - | 287 | 778 | 347 | 2273 | TL | 10 | 134A2 | |
| 12-16.5 | 9.75 | - | 332 | 831 | 370 | 2428 | TL | 12 | 145A2 | |
| 14-17.5 | 10.5 | - | 393 | 934 | 416 | 2729 | TL | 14 | 155A2 | 147A3 | |
| 15-19.5 | 11.75 | - | 433 | 1020 | 455 | 2981 | TL | 14 | 160A2 | 153A3 | |
IMPERIAL
METRIC
Technical Table 01
| TYRE SIZE | RIM SIZE | REC. RIM | ALT. RIM | UNLOADED DIMENSIONS (mm) | PLY RATING | LOAD INDEX SPEED SYMBOL | ||||
| SW | OD | SLR | RC | |||||||
| 15.0/70-18 | 18 | W13 |
W17 W19 |
400 | 980 | 440 | 2886 | 14 | 128 A8 |
 |
| 16 | 132 A9 |
|
||||||||
Technical Data
| Tyre Size | Rec. RIM (inch) |
Alt. RIM (inch) |
Unloaded dimensions (mm) | Type | Ply Rating | Load Index & Speed Symbol | Fabric | Load table | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Section Width | Overall Diameter | Static Load Radius | Rolling Circumference | ||||||||
