Motor Grader
CR 09
The CR 09 L-2/G-2 tyre is designed for use in Pick N Carry cranes and Motor Graders. Its directionally oriented lugs with ideal land and sea ratio, provide consistent traction. Its tough carcass enables the tyre to take long hours of severe duty application.
L-2/G-2
A8
Bias
Suitable for
Motor Grader
Telescopic Handler
Technical Data
| TYRE SIZE | REC. RIM (inch) | ALT. RIM (inch) | UNLOADED DIMENSIONS (mm) | TYPE | PLY RATING | LI & SS | ||||
|---|---|---|---|---|---|---|---|---|---|---|
| SW | OD | SLR | RC | |||||||
| 13.00-24 TG | 8.00/1.4 | - | 350 | 1280 | 590 | 3750 | TT | 12 | 143A8 | |
| 13.00-24 TG | 8.00/1.4 | - | 350 | 1280 | 590 | 3750 | TT/TL | 16 | 149A8 | |
IMPERIAL
METRIC
Technical Table 01
| TYRE SIZE | RIM SIZE | REC. RIM | ALT. RIM | UNLOADED DIMENSIONS (mm) | PLY RATING | LOAD INDEX SPEED SYMBOL | ||||
| SW | OD | SLR | RC | |||||||
| 15.0/70-18 | 18 | W13 |
W17 W19 |
400 | 980 | 440 | 2886 | 14 | 128 A8 |
 |
| 16 | 132 A9 |
|
||||||||
Technical Data
| Tyre Size | Rec. RIM (inch) |
Alt. RIM (inch) |
Unloaded dimensions (mm) | Type | Ply Rating | Load Index & Speed Symbol | Fabric | Load table | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Section Width | Overall Diameter | Static Load Radius | Rolling Circumference | ||||||||
