BL54 L-4 tyre is designed for backhoe loaders and industrial tractors are engaged in severe duty applications in construction sites, municipal work and on sites that have highly abrasive surfaces.
Deep tread directional pattern with large central blocks and strong shoulder blocks built with special cut and chip resistant compound that provides significantly longer life when compared to standard R-4 tyres.
Optimally spaced lugs with high solid to void ratio provide superior traction on hard and abrasive surfaces. Providing consistent and dependable performance in severe duty conditions.
L-4
A8
Bias
Suitable for

Backhoe Loader

Industrial Tractor

Compact Wheel Loader

Telescopic Handler
Technical Data
BL 54 JUMBO
...
TYRE SIZE | REC. RIM (inch) | ALT. RIM (inch) | UNLOADED DIMENSIONS (mm) | TYPE | PLY RATING | LI & SS | ||||
---|---|---|---|---|---|---|---|---|---|---|
SW | OD | SLR | RC | |||||||
12.5/80-18 | W9 | - | 310 | 965 | 445 | 2810 | TL | 14 | 132A8 | |
16.9-24 | W15 | - | 445 | 1314 | 585 | 3770 | TL | 12 | 149A8 | |
19.5L-24 | W15L | - | 500 | 1320 | 590 | 3795 | TL | 14 | 154A8 | |
16.9-28 | W15 | - | 445 | 1405 | 645 | 4140 | TL | 14 | 156A8 |
IMPERIAL
METRIC
Technical Table 01
TYRE SIZE | RIM SIZE | REC. RIM | ALT. RIM | UNLOADED DIMENSIONS (mm) | PLY RATING | LOAD INDEX SPEED SYMBOL | ||||
SW | OD | SLR | RC | |||||||
15.0/70-18 | 18 | W13 |
W17 W19 |
400 | 980 | 440 | 2886 | 14 | 128 A8 |
![]() |
16 | 132 A9 |
![]() |
Technical Data
Intl.
US
Tyre Size | Rec. RIM (inch) |
Alt. RIM (inch) |
Unloaded dimensions (mm) | Type | Ply Rating | Load Index & Speed Symbol | Fabric | Load table | |||
---|---|---|---|---|---|---|---|---|---|---|---|
Section Width | Overall Diameter | Static Load Radius | Rolling Circumference |
