Backhoe Loader
BL 36
The TVS Eurogrip BL 36 is a non-directional tyre adapted from the design for large OTR machines. It is designed for use in machines engaged in construction jobs. The non-directional lug design is ideal for constant forward and backward movement, especially for machines that are used for scooping and loading. The tyre is built with special compound to resist cuts and have reduced abrasion, providing longer life in severe working conditions.
R-4
A8
Bias
Suitable for
Backhoe Loader
Self Loading Concrete Mixer
Compact Wheel Loader
Site Dumper
Technical Data
| TYRE SIZE | REC. RIM (inch) | ALT. RIM (inch) | UNLOADED DIMENSIONS (mm) | TYPE | PLY RATING | LI & SS | ||||
|---|---|---|---|---|---|---|---|---|---|---|
| SW | OD | SLR | RC | |||||||
| 12.5/80-18 | W9 | - | 315 | 980 | 440 | 3030 | TT | 16 | 148A8 | 135A8 | |
IMPERIAL
METRIC
Technical Table 01
| TYRE SIZE | RIM SIZE | REC. RIM | ALT. RIM | UNLOADED DIMENSIONS (mm) | PLY RATING | LOAD INDEX SPEED SYMBOL | ||||
| SW | OD | SLR | RC | |||||||
| 15.0/70-18 | 18 | W13 |
W17 W19 |
400 | 980 | 440 | 2886 | 14 | 128 A8 |
 |
| 16 | 132 A9 |
|
||||||||
Technical Data
| Tyre Size | Rec. RIM (inch) |
Alt. RIM (inch) |
Unloaded dimensions (mm) | Type | Ply Rating | Load Index & Speed Symbol | Fabric | Load table | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Section Width | Overall Diameter | Static Load Radius | Rolling Circumference | ||||||||
